Advanced Flow Made Easy

WeatherTRAK OptiFlow XR® is an advanced flow management controller available in conventional wire or 2-Wire configurations. OptiFlow XR leverages its visual and easy-to-use interface making it easy to manage complex flow across entire sites. By enabling controllers to share information in the cloud, OptiFlow XR optimizes how, when and where watering takes place within your water windows.

Features

Hundreds of controllers can share information and receive daily instructions about irrigation. Your site’s maximum water flow potential is calculated to keep things running as close to your site’s hydraulic capacity as possible. Define your water windows, pipe thresholds, and learn station flow, then let OptiFlow XR handle the schedules.

Sites with complex hydraulics are now easier to manage than ever

Reduce irrigation times to meet water windows or site demands

OptiFlow Conventional

  • Support for 12 to 96 stations
  • Six station modularity
  • Ten-year warranty
  • Worry-free Wireless Warranty™ covers cellular technology upgrades

OptiFlow 2-Wire

  • Supports up to 200 stations
  • Ten-year warranty
  • Worry-free Wireless Warranty™ covers cellular technology upgrades

Features

Programming

  • Eight simultaneous programs with five program modes and two start times
  • Program all settings at controller, or remotely
  • Independent station programming (72 cycles/ station) with automated cycle and soak
  • User-defined water days and water windows per program to comply with agency regulations
  • Built-in WeatherTRAK Scheduling Engine optimizes by plant, soil, sprinkler, sun exposure, and slope data
  • Automated daily runtime adjustments using site-specific ET Everywhere weather data
  • Percent adjust to enable fine-tuning by station
  • Automated skip days based on zone-specific soil moisture depletion
  • Runtime rationing protects plant health under constricted water windows
  • Stacked station manual watering from 1-99 minutes

The HydroPoint H2O platform leverages the industry’s most dynamic 2-Wire technology to provide a powerful solution for smart controllers, valve decoders, and accessories. The system includes:

  • Smart controllers capable of flow management, real-time alerts, and cloud-based control
  • Valve decoders with bi-directional communication, multi-valve management, and built-in LEDs
  • Accessories that enable control over master valves, flow sensor data, and pump start relays
  • Supports up to 4 master valves and 4 flow sensors using direct connect terminals and/or 2-wire decoders

Integrated Flow

  • Mainline/catastrophic break detection and shutdown
  • Real-time station-specific flow monitoring and control
  • Local and remote station-learned flow
  • Fault detection, diagnostics, and alerts
  • Supports up to four flow sensor inputs and master valve outputs
  • Supports normally open or normally closed master valves
  • Customizable flow alert thresholds
  • Upgradable to OptiFlow® for advanced flow management and multi-controller automatic scheduling
  • Supports Data Industrial®, CST, Netafim flow sensors and custom “K and offset” values
  • Compatible with WeatherTRAK FlowLink®, FlowShare, Flow3, and FlowHD

Advanced Flow & Control

  • Panel lock with pin code for security
  • Up to 10 controllers can share a point of connection on a mainline
  • Up to 10 Manager controllers can support up to 40 POCs on a single mainline
  • Up to 30 controllers can share a single mainline with multiple POCs
  • Dynamic scheduling and optimization of hundreds of thousands of stations across a water source.
  • Optimize hundreds of mainlines and hundreds of thousands of stations across a water source
  • Minute level flow resolution stored in the cloud
  • Newly Optimized schedules sent to the controller each day based on the latest ET Weather
  • Set Catastrophic leak thresholds
  • Access via desktop, tablet, and mobile with WeatherTRAK Central and WeatherTRAK Mobile

Hardware

  • Integrated flow sensor support included
  • Dedicated master valve and pump start
  • Commercial-grade screw-less wire terminals
  • Built-in amp meter for fault protection and diagnostics
  • Cellular radio and first year of WeatherTRAK Central service included
  • LTE cellular communication for the best coverage and performance
  • 32-pin connector for hardware remote like the TRC Commander and Irritrol® ProMax™(OptiFlow XR Conventional only)
  • New features and firmware pushed over-the-air using WeatherTRAK Cloud Update
  • Share one rain sensor across multiple controllers with RainShare™
  • Robust built-in surge protection integrated directly into the controller
OptiFlow

OptiFlow

WeatherTRAK with OptiFlow is a ground breaking solution that helps manage restrictive water windows, keeping things running as close to capacity as possible and delivering water where it’s needed with the time available. Working in conjunction with WeatherTRAK OptiFlow XR, WeatherTRAK ET Pro3 controllers and WeatherTRAK Central, OptiFlow is the industry’s first solution to optimize and maximize flow across an entire site from the cloud.

Maximize Water Windows

Imagine a scenario where you have multiple controllers that share a single mainline from a single point of connection. Each controller has its own water windows and programming requirements.

Instead of forcing you to figure out the schedule for hundreds of stations across multiple controllers, OptiFlow does the work for you. Once the OptiFlow XR controllers are joined together as a flow group, they operate as a single system, sharing flow data and coordinating schedules for optimal efficiency.

Models

Models

OptiFlow XR (CWM)

12 – 48 Station
Conventional Wiring
WALL MOUNT: Cold-Rolled Steel

18-gauge, powder-coated, cold-rolled steel, wall mount enclosure with key-lock entry.

OptiFlow XR (CWM)

72 & 96 Station Conventional Wiring
WALL MOUNT: Cold-Rolled Steel

18-gauge, powder-coated, cold-rolled steel, wall mount enclosure with key-lock entry. Two separate enclosures.

OptiFlow XR 2-Wire (CWM)

48 & 96 & 200 Station
WALL MOUNT: Cold-Rolled Steel

18-gauge, powder-coated, cold-rolled steel, wall mount enclosure with key-lock entry. Station valve decoders not included.

Cold-Rolled Steel Pedestal

16-gauge, powder-coated, cold-rolled steel pedestal enclosure w/ key-lock entry. Controller sold separately.

OptiFlow XR (SWM)

12 – 48 Station Conventional Wiring
WALL MOUNT: Stainless Steel

18-gauge, stainless steel, wall mount enclosure w/ key-lock entry.

OptiFlow XR (SWM)

72 & 96 Station Conventional Wiring
WALL MOUNT: Stainless Steel

18-gauge, stainless steel, wall mount enclosure w/ key-lock entry. Two separate enclosures.

OptiFlow XR 2-Wire (SWM)

48 & 96 & 200 Station
WALL MOUNT: Stainless Steel

18-gauge, stainless steel, wall mount enclosure w/ key-lock entry. Station valve decoders not included.

Stainless Steel Pedestal

Sub-assembly for Pedestal Conversion

16-gauge, stainless steel, pedestal enclosure w/ key-lock entry. Controller sold separately.

Enclosures

OptiFlow XR (SPH)

12 – 48 Station Conventional Wiring
Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated front-entry enclosure w/ key-lock entry. VIT Strongbox enclosure model
no. SB-18SS.

OptiFlow XR 2-Wire (SPH)

48 & 96 Station
Heavy-Duty, Front-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated front-entry enclosure w/ key-lock entry. VIT Strongbox enclosure model
no. SB-18SS. Station valve decoders not included.

OptiFlow XR (SPT)

12 – 48 Station Conventional Wiring
Heavy-Duty, Slope-Top, Top-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated slope-top, top-entry enclosure w/ key-lock entry to upper and lower compartments. VIT Strongbox Enclosure model no. SB-16SS.

OptiFlow XR 2-Wire (SPT)

48 & 96 & 200 Station
Heavy-Duty, Slope-Top, Top-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated slope-top, top-entry enclosure w/ key-lock entry to upper and lower compartments. VIT Strongbox Enclosure model no. SB-16SS.Station valve decoders not included.

OptiFlow XR (SPS)

12 – 48 Station Conventional Wiring
Light-Duty, Front-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

16-gauge stainless steel, NEMA 3R rated front-entry enclosure w/ key-lock entry. VIT Strongbox Enclosure model
no. LD-16S.

OptiFlow XR 2-Wire (SPH)

48 & 96 & 200 Station
Heavy-Duty, Front-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated front-entry enclosure w/ key-lock entry. VIT Strongbox enclosure model
no. SB-18SS. Station valve decoders not included.

OptiFlow XR (SPT)

12 – 48 Station Conventional Wiring
Heavy-Duty, Slope-Top, Top-Entry Stainless Steel Controller

Includes control panel, antenna, and terminal boards pre-installed

14-gauge stainless steel, NEMA 3R rated slope-top, top-entry enclosure w/ key-lock entry to upper and lower compartments. VIT Strongbox Enclosure model no. SB-16SS.

Chassis

OptiFlow XR (Chassis 1)

12 – 48 Station Conventional Wiring
Chassis for Wall Mount Enclosure

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any wall-mount enclosure 18”w x 18”h x 10”d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-18SW series). Pancake LTE Antenna included.

OptiFlow XR (Chassis 1)

72 & 96 Station Conventional Wiring
Chassis for Wall Mount Enclosure

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any wall mount enclosure 18”w x 18”h x 10”d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-18SW series). Pancake LTE Antenna included. Two separate units.

OptiFlow XR 2-Wire (Chassis 1)

48 & 96 & 200 Station
Chassis for Wall Mount Enclosure

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any wall mount enclosure 18”w x 18”h x 10”d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-18SW series). Pancake LTE Antenna included. Station valve decoder not included.

OptiFlow XR (Chassis 2)

12 – 48 Station Conventional Wiring
Chassis for Heavy-Duty Front-Entry Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any heavy-duty front-entry pedestal 18” w x 36” h x 12” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-18SS, SB-36SS, or SB-18DSS) Fits in WeatherTRAK SPH series enclosures. Pancake LTE Antenna included.

OptiFlow XR (Chassis 2)

72 & 96 Station Conventional Wiring
Chassis for Heavy-Duty Front-Entry Pedestal
18-gauge anodized, pre-assembled, aluminum back panel retrofits into any heavy-duty front-entry pedestal 18” w x 36” h x 12” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-18SS, SB-36SS, or SB-18DSS) Fits in WeatherTRAK SPH series enclosures. Pancake LTE Antenna included. Two separate units.

OptiFlow XR 2-Wire (Chassis 2)

48 & 96 & 200 Station
Chassis for Heavy-Duty Front-Entry Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any heavy-duty front-entry pedestal 18” w x 36” h x 12” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-18SS series) Fits in WeatherTRAK SPH series enclosures. Pancake LTE Antenna included. Station valve decoders not included.

OptiFlow XR (Chassis 4)

12 – 48 Station Conventional Wiring
Chassis for Heavy-Duty Slope-Top Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any slope-top, top-entry pedestal 16” x 38” h x 15.5” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-16SS series) Fits in WeatherTRAK SPT series enclosures. Pancake LTE Antenna included.

OptiFlow XR (Chassis 4)

72 & 96 Station Conventional Wiring
Chassis for Heavy-Duty Slope-Top Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any slope-top, top-entry pedestal 16” x 38” h x 15.5” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-16SS series) Fits in WeatherTRAK SPT series enclosures. Pancake LTE Antenna included. Two separate units.

OptiFlow XR 2-Wire (Chassis 4)

48 & 96 & 200 Station
Chassis for Heavy-Duty Slope-Top Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any slope-top, top-entry pedestal 16” x 38” h x 15.5” d or larger. (e.g., VIT Strongbox Enclosure Pedestal SB-16SS series) Fits in WeatherTRAK SPT series enclosures. Pancake LTE Antenna included. Station valve decoders not included.

OptiFlow XR (Chassis 5)

12 – 48 Station Conventional Wiring
Chassis for Light-Duty Front-Entry Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any front-entry pedestal 16.75” w x 30” h x 8.25” d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-16S series) Fits in WeatherTRAK SPS series enclosures. Pancake LTE Antenna included.

OptiFlow XR (Chassis 5)

72 & 96 Station Conventional Wiring
Chassis for Light-Duty Front-Entry Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any front-entry pedestal 16.75” w x 30” h x 8.25” d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-16S series) Fits in WeatherTRAK SPS series enclosures. Pancake LTE Antenna included. Two separate units.

OptiFlow XR 2-Wire (Chassis 5)

48 & 96 & 200 Station
Chassis for Light-Duty Front-Entry Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into any front-entry pedestal 16.75” w x 30” h x 8.25” d or larger. (e.g., VIT Strongbox Enclosure Pedestal LD-16S series) Fits in WeatherTRAK SPS series enclosures. Pancake LTE Antenna included. Station valve decoders not included.

OptiFlow XR (Chassis 7)

12 – 48 Station Conventional Wiring
Chassis for Rain Bird® Maxicom® Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into Rain Bird® Maxicom® ESP-Sat stainless steel enclosure. Pancake LTE Antenna included.

OptiFlow XR (Chassis 7)

72 & 96 Station Conventional Wiring
Chassis for Rain Bird® Maxicom® Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into Rain Bird® Maxicom® ESP-Sat stainless steel enclosure. Pancake LTE Antenna included. Two separate units.

OptiFlow XR 2-Wire (Chassis 7)

48 & 96 & 200 Station
Chassis for Rain Bird® Maxicom® Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into Rain Bird® Maxicom® ESP-Sat stainless steel enclosure. Pancake LTE Antenna included.

OptiFlow XR (Chassis 8)

12 – 96 Station Conventional Wiring
Chassis for Heavy-Duty Slope-Top Wide Pedestal

18-gauge anodized, pre-assembled, aluminum back panel retrofits into wide slope-top pedestal 24”w x 30”h x 38”d or larger. (e.g., Strongbox Enclosure Pedestal SB-22SS) Fits in WeatherTRAK STW series enclosures. Pancake LTE Antenna included.

Specifications

Specifications

OptiFlow XR Conventional

Electrical & Enclosure Specifications

  • Support for 12 to 96 stations
  • Six station modularity
  • Ten-year warranty
  • Worry-free Wireless Warranty™ covers cellular technology upgrades
Input Power:120 VAC +/- 10%, (60 Hz) or 220 VAC +/- 10%, (60 Hz)
Output Power:24 VAC (60 Hz)1.0 Amp (1000mA) max per station output including a pump start1.0 Amp (1000mA) max per master valve output3.0 Amps (80 VA) total loadUp to 17 terminal outputs energized simultaneously (8 stations, 1 manual, 4 pump starts, 4 master valves)
Consumptive Power:Idle State: 2.5 Watts Power
Maximum Power Requirements for Irrigation State: 70 Watts
Certifications:EPA WaterSense Approved, FCC Certified, UL Listed, 100% SWAT-tested
Enclosure Options:Wall Mount Enclosures16 gauge wall mount enclosure available in stainless and powder coated finishesKey-hole mounting for wall mount enclosures for easy installationEasily adapts to a small 14 gauge pedestal; available in two finishes
VIT Strong Box Stainless SteelPedestal EnclosuresRetrofit Chassis for Existing EnclosuresAll come with key lock entryNEMA-3R weather-resistant

OptiFlow 2-Wire

Electrical & Enclosure Specifications

  • Supports up to 200 stations
  • Ten-year warranty
  • Worry-free Wireless Warranty™ covers cellular technology upgrades
Input Power:120 VAC +/- 10%, (60 Hz) or 220 VAC +/- 10%, (60 Hz)
Output Power:Station Valve: 24VAC up to 600mA max including a pump startMaster Valve: 24VAC Valves up to 900mAFlow Sensor: Loop Current 4mA, 0-200HzTotal Load: 3.0 Amps (80VA)Up to 17 terminal outputs energized simultaneously (8 stations, 4 manual, 4 pump starts, 4 master valves)
Consumptive Power:Idle State: 3 Watts Power
Maximum Power Requirements for Irrigation State: 70 Watts
Certifications:EPA WaterSense Approved, FCC Certified, UL Listed, 100% SWAT-tested
Enclosure Options:Wall Mount Enclosures16 gauge wall mount enclosure available in stainless and powder coated finishesKey-hole mounting for wall mount enclosures for easy installationEasily adapts to a small 14 gauge pedestal; available in two finishes
VIT Strong Box Stainless SteelPedestal EnclosuresRetrofit Chassis for Existing EnclosuresAll come with key lock entryNEMA-3R weather-resistant
Compatible Wire Options:Coleman Cables #51452Paige Electric P7072D, P7296D, P7350D,
and P7354DRegency 14/2 and 12/2 Maxi CableToro Decoder CableHunter Decoder Jacketed Service Wire
DEC12/2BE and DEC14/2BE
Product Documents
Accessories

2-Wire Decoders

Single Station Valve Decoder

WeatherTRAK H2O 2-Wire single station valve decoder. Includes four 3MTM DBR/Y-6 splice kits. Available pre-programmed.

Two Station Valve Decoder

WeatherTRAK H2O 2-Wire two station valve decoder. Includes six 3MTM DBR/Y-6 splice kits. Available pre-programmed.

Master Valve Decoder

WeatherTRAK H2O 2-Wire master valve decoder. Includes four 3MTM DBR/Y-6 splice kits.

Pump Start Decoder

WeatherTRAK H2O 2-Wire pump start decoder. Includes four 3MTM DBR/Y-6 splice kits.

Flow Sensor Decoder

WeatherTRAK H2O 2-Wire flow sensor decoder. Includes four 3M™ DBR/Y-6 splice kits. Available pre-programmed.

Surge Arrestor Decoder

WeatherTRAK H2O 2-Wire surge arrestor decoder. Includes four 3M™ DBR/Y-6 splice kits.

OptiFlow XR Conventional

6-Station Key

Station module to increase station count by 6 stations. Compatible with OptiFlow XR, and ET Pro3

24-Station Output Board

24-station output board, to expand an OptiFlow XR, ET Pro3 above 24 stations. Does not include station keys which are sold separately.

Remote Extension Kit

Consists of two new mini chassis and 40-foot long connector cable.

OptiFlow XR 2-Wire

2-Wire 48 Station Expansion Key

WeatherTRAK 2-wire station expansion key: from 48 to 96 stations.
