WeatherTRAK® LC+

Smart Irrigation Just Got Simple™

When you’re looking for easy to use, powerful, cloud-based irrigation, the WeatherTRAK® LC+ controller gives you everything you need to easily manage a single, light commercial property or hundreds of sites.

The WeatherTRAK LC+ brings sophisticated automation technology to light commercial properties and eliminates water waste based on site-specific data from the ET Everywhere™ weather service, all while protecting plant health and delivering an attractive landscape. All-inclusive options available, which include subscription and warranty for ten years.

The WeatherTRAK LC+ enables you to manage more sites, use less water, and keep landscapes looking great. Its LTE cellular technology and cloud-based management ensure you always have the latest ET weather data and system updates.

It is easy to select in preconfigured options for 6 to 36 stations (expandable in 6-station increments), and can optionally monitor flow to detect head or pipe breaks.

It is easy to install, and ready to provide the efficiency and savings of weather-based irrigation right out of the box. You’ll be up and running in minutes, not hours.

It is easy to use, program, and control with either the sensitive and intuitive controller interface, WeatherTRAK Central online, or with your
mobile phone.


  • Support for 6 to 36 stations plus flow sensor, master valve, and pump start, using conventional wiring
  • Expands in Six station increments (6 -18 or 24-36)
  • Three-year warranty
  • Worry-free Wireless Warranty covers cellular technology upgrades


  • Expand with 6-station expansion keys and an optional key for station-based flow
  • Automated daily runtime adjustments using site-specific ET Everywhere™ weather data
  • Cloud-based scheduling engine optimizes by microclimate, plant, soil, sprinkler type, and slope
  • Independent station programming (72 cycles/station), automated cycle-and-soak
  • User-defined water days and water windows
  • Program settings at controller, using mobile app, or remotely with
  • Up to four simultaneous programs for 24-36 stations
  • Up to 7 simultaneously energized outputs: 4 programs, 1 manually operated valve, 1 master valve, and 1 pump start
  • Integrated LTE cellular radio and antenna; over-the-air updates
  • Supports wired or wireless rain sensor; RainShare™ enables multiple controllers to share a single rain sensor
  • Daylight-bright backlit LCD display
  • Built-in fault protection and diagnostics
  • Lightning protection up to 6 kV

Flow Monitoring and Master Valve Control

  • Mainline/catastrophic break detection and shutdown
  • Real-time, station-specific flow monitoring and control
  • Learned flow determined at station level
  • Fault detection, diagnostics, and alerts
  • Normally open or normally closed master valve

Note: Flow monitoring requires an optional key



6 to 18 Station

High-impact plastic, NEMA 3R rated, key-lock entry, wall mount enclosure. Includes metal mounting plate with built-in bubble level


24 to 36 Station

High-impact plastic, NEMA 3R rated, key-lock entry, wall mount enclosure. Includes metal mounting plate with built-in bubble level

Cold-Rolled Steel Pedestal

Sub-assembly for Pedestal Conversion

16-gauge, powder coated, cold-rolled steel pedestal enclosure and LC+ pedestal adapter w/ key-lock entry.

Controller sold separately.

WeatherTRAK Delivers Results


Electrical & Enclosure Specifications

Input Power:120 VAC +/- 10%, (60 Hz)
Output Power:24 VAC RMS and 1.6 amps maximum total; station and master valve outputs each
1.0 amps maximum
Consumptive Power:Idle State: 2.5 Watts Power
Full load: 48 Watts
Transformer Output:56 VA (24 VAC x 2.33 amps) with a 2.0 amp slo-blo fuse
Certifications:EPA WaterSense Approved, FCC Certified, UL Listed, 100% SWAT-tested
Enclosure Options:Plastic wall-mount enclosure with key-lock entry12” w x 8” h x 5-3/4” d, 5 lbs.UL Listed NEMA-3R weather-resistant enclosureIntegrated bubble-level mounting plate with keyhole mounting for easy installationIndustrial-grade screwless wire terminals

Product Catalog

Technical Specifications

Design Specifications

Each product zip file contains specification drawings in the following formats: DWG, DXF, JPEG and PDF
