WeatherTRAK® Flow3
Flow3 is our most flexible and affordable hydrometer. Combined with a WeatherTRAK® controller, you’ll get the protection of a master valve, visibility of a flow sensor and submetering capabilities of a water meter. Because the flow sensor, master valve and water meter are all integrated into a single, powerful unit, it’s easy to install, even in tight locations.
Flow3 is ideal for:
- New system installations
- Retrofitting existing systems
- Sites with limited install space
- High pressure situations
Features
Accurate performance for commercial sites
- Sizes: 1 ½” (Union), 2” (Threaded), 3”, 4” and 6” (Flanged)
- 8 to 860 gallons per minute flow range
- Accuracy across a wide flow range (up to ± 2% see chart on back)
Powerful mainline control
- Prevent catastrophic water loss
- Double-chambered valve provides quick-acting and positive opening and closing
Easy to read registerProvides on-site submetering
- Two register options: Photo Diode – high frequency or Reed Switch – low frequency
- Odometer style register displays won’t lose data
Easy to install
- Requires no straight pipe upstream or downstream of unit
- Low installation cost vs. installing each component separately
- Ideal for installations where space is limited
Built to last
- Heavy-duty cast iron construction with corrosion-resistant body
- Stainless steel encapsulated registers guaranteed against fogging due to moisture
Models
Register Options
Photo Diode
High frequency pulse output
For systems containing drip and/or high efficiency/rotary nozzles zones
- From 0.005 gallons per pulse
- 10 to 200 pulses per second (depending on flow rate)
- Superior leak visibility
- Combines an IR light source and a light sensitive diode (power supply included)
Reed Switch
High frequency pulse output
For systems with station flow rates of 10+ GPM and are less concerned about small leaks
- 1 gallon per pulse
- Leak indicator dial in the center of register
- Magnetic coupling activated
Performance Data
| SIZE | LOWEST FLOW WITHIN ± 5% ACCURACY (GPM) | LOWEST FLOW WITHIN ± 2% ACCURACY (GPM) | NOMINAL FLOW WITHIN ± 2% ACCURACY (GPM) | MAXIMUM FLOW WITHIN ± 2% ACCURACY (GPM) |
|---|---|---|---|---|
| 1 ½” | 1.8 | 4.4 | 44 | 55 |
| 2″ | 5.3 | 20 | 66 | 95 |
| 3″ | 14 | 53 | 176 | 220 |
| 4″ | 21 | 79 | 264 | 380 |
| 6″ | 53 | 198 | 660 | 860 |
Flow Range
| SIZE | MIN GPM ± 5% | MAX GPM ± 5% |
|---|---|---|
| 1 ½” | 1.8 | 55 |
| 2″ | 5.3 | 95 |
| 3″ | 14 | 220 |
| 4″ | 21 | 380 |
| 6″ | 53 | 860 |
Fiction Loss v. Pressure Loss (psi)
Benefits
- Highly accurate performance makes it ideal for most commercial sites.
- Built-in master valve so if a break is detected, the master valve will automatically close and prevents damage.
- Easy to read register with sub-metering and displays that won’t lose data.
- Easy to install.
- Built to last: based on heavy-duty construction and no moving parts.
Specifications
Download WeatherTRAK Flow3 Specifications (ZIP, 8MB)
Contains: (PDF) (DWG) (DFX) (JPEG)
- Sizes: 1 1/2″, 2″, 3″, 4″, and 6″
- Maximum working pressure: 235 psi
- Minimum working pressure: 14 psi
- Body: Cast iron, polyester coated
- Connections: Threaded, flanged
- Register Types: Reed Switch, Photo Diode
- Register: Odometer style with 3 fractional dials
- Power: photo diode requires a constant supply of DC power
- Valve diaphragm: Reinforced natural rubber
- Flanges: Drilled according to ANSI specification
- Standards: EEC approval (class A)
- Compatible with: ET Pro3, ET Pro3 2 wire, LC Controllers, WeatherTRAK FlowLink, FlowShare, and WeatherTRAK Central
